TIRES RECYCLING PLANT

TURNKEY PLANT FOR TIRE SHREDDING

Download Plant Sheet

TIRE SHREDDING

99% PURE END PRODUCT

Recycling plants for end-of-life tires make it possible to obtain secondary raw material of different particle sizes, while at the same time separating other components, such as steel and textile fiber. The plant is equipped with a multi-step cleaning system to ensure complete separation of the textile fiber and obtain a granulated product with 99% purity level.

The suction system is supported by filters and fire-fighting systems for specific dust control in compliance with current regulations, including safety regulations.

COMPLETE TIRE TREATMENT

OPTIMAL MATERIAL SEPARATION

The stages of the production cycle for tire treatment include:

PRIMARY TREATMENT Volumetric reduction down to 100 mm.
GRINDING Reduction of rubber granule material down to about 20 mm.
GRANULATION Reduction of rubber granule material down to 0 to 4 mm.
CLEANING OF THE RUBBER GRANULE Following the separation of the granule into 3 different sizes 0-1 / 1-2 / 2-4 mm, the marerial undergoes treatments aimed at separating the remaining textile fiber, which is collected throughout the process by a centralized suction and filtration system.

EÔÇÖ operativo lÔÇÖimpianto di Minsk per il trattamento degli pneumatici

Machines used in the plant

FMS GRANULATORS

Granulator designed for grinding components from the injection moulding and blow moulding process, extrusion parts, bulk and reel film, blocks, pre-shredded tyres.

SHREDDER DOUBLE SHAFT SHREDDER TB

Twin-Shaft Shredders designed to achieve precise volumetric reduction and roughing of the material, with partial control of the output size

SHREDDER DOUBLE SHAFT SHREDDER TX 1600

Primary Shredder TX 1600 specifically for End-of-Life Tires with a blade system that allows for output material with precise characteristics in terms of production and clean cut

MR SINGLE-SHAFT GRINDERS

Single-shaft grinder for processing tires and materials with high specific weight
